Miscellaneous

Besides high quality trailers OJB-industries also makes top of the line industrial grade steel products for farming operations – like root rake buckets, or mechanical loading ramps.

We have the newest version of Solidworks 3D software which allows us to model, simulate and analyse all kinds of machines and structures. Please contact us to see how we can help you with any customized job.

OJB-industries has different models of Crowd Gates. Contact us for details.

Root Rake Bucket

OJB industries developed a root rake bucket with mechanical for on your excavator. With this bucket you can clean fence lines, clear bush and stumps and load brush. The teeth for the rake are made of 1.5” thick A571 Steel and are attached with each other through a 3”solid shaft. Plates made out of 1”steel are protecting the quick attach or end of the boom. Root rake buckets can be made for any size excavator with quick attach or pin on. Mechanical thumb is optional.

We have the newest version of Solidworks 3D software which allows us to model, simulate and analyse all kinds of machines and structures. Please contact us to see how we can help you with any customized job.

Piranha Straw Shredder

For a large Dutch goat farmer we supplied our unique Piranha straw shredder. This straw shredder is loader mounted and will handle 3’x3′, 3′ x 4,’ 4’x4′ bales. Basically any size large square bale on the market. The bales are getting cut by 48 knives which are mounted on 2 6 inch drums. The knives are hydraulically driven and can turn in 2 directions. The straw shredder can be used by driving through the pen.

Payloader Gravel Bucket

Large volume Payloader Bucket

Silage Blade

OJB-industries has different models of loading ramps. All loading ramps have a 10 degree load angle, and are adjustable in height from 3 to 5 feet loading height. They can be equipped with a leveling platform at the end or be a straight ramp.

Key features:

• Bar grating floor which is self-cleaning and always gives you traction
• Manual adjustable height
• Adjustable hitch
• 8, 10 or 12 feet width
• Solid, or pneumatic tires
• Hot dipped galvanized or painted finish

Every ramp will be designed to your needs and application. Contact us for details.
